Terran R Market Demand Updated by Relativity Space
Relativity Space is accelerating the company’s focus on Terran R to meet significant and growing market demand, following the successful flight to space of the Terran 1 3D printed rocket.
“Our first chapter as a company was to prove to the world 3D printed rockets were viable. We just did that with Terran 1. Our second chapter is to build the next great launch company with Terran R.”
Relativity Space co-founder and CEO Tim Ellis.
Terran R is a reusable, 3D printed, medium-to-heavy lift orbital launch vehicle. As a two-stage, 270-foot-tall rocket with an 18-foot diameter and a 5-meter payload fairing, Terran R is a customer-centric next-generation launch vehicle designed to meet the needs of commercial companies and government entities sending payloads into LEO, MEO, GEO, and beyond. Terran R's architecture choices enable accelerated development and the ability to deliver a rapidly scaling launch cadence for customers. Terran R will prioritize first stage reusability, with the capability of launching 23,500kg to Low Earth Orbit (LEO) or 5,500kg (≈12,125 pounds) to a Geosynchronous Transfer Orbit (GTO), both with downrange landing, or up to a maximum payload of 33,500kg (≈74,000 pounds) to LEO in expendable configuration. Horizontal integration to the vehicle will be supported through a standard Payload Attach Fitting (PAF) interface, with payload integration configurations available for clusters of constellation satellites, single large satellites, or other unique spacecraft. Starting in 2026, Terran R will launch from Space Launch Complex 16, the company’s orbital launch site at Cape Canaveral, Florida.
“Our first chapter as a company was to prove to the world 3D printed rockets were viable. We just did that with Terran 1. Our second chapter is to build the next great launch company with Terran R,” said Relativity Space co-founder and CEO Tim Ellis. “Terran R is the most customer-centric next-generation launch vehicle. It is not a conventional rocket. This is a new breed of launch vehicle with the right payload performance, reliability, focus on speed of development, optimized reusability, focus on scalability of launch ramp rate, and ultimately cost reduction baked into the architecture design and our program plans from day one.”
Designed for rapid reusability and development iteration speed, Terran R is a 3D printed rocket, with initial versions using aluminum alloy tank straight-section barrels in a hybrid manufacturing approach, which allows Relativity to meet the rapid launch and ramp rate timelines necessary to serve overwhelming market demand, including servicing Relativity’s signed customer backlog of $1.65B in Launch Service Agreements (LSAs) and additional several billion dollars in active customer LSA dialogue. Each Terran R requires approximately 6 times more 3D printing by mass than Terran 1. 3D printing technology for Terran R is strategically used to reduce vehicle complexity and improve manufacturability, with continued company focus on redefining what is possible with large scale additive manufacturing after successfully proving the viability of 3D printed rockets with Terran 1. Initially, Terran R will use the same proprietary printed aluminum alloy as flown on Terran 1 with a focus on supply chain scaling. However, a third-generation aluminum alloy, designed for improved performance of an orbital vehicle mission life beyond 20 reusable flights, is in active development, which is accelerated by the aid of artificial intelligence-based alloy discovery tools.
Terran R’s first stage will be outfitted with 13 3D-printed gas generator cycle Aeon R LOx/Methane rocket engines each capable of 258,000 lb. sea level thrust, while its second stage houses a single LOx/Methane Aeon Vac engine with 279,000 lb. vacuum thrust. These engines benefit from Relativity’s advanced experience developing gas generator engines and vehicle stages with the oxygen/methane propellant combination. The engine composition on the first stage is comprised of four outer fixed engines aligned underneath four landing legs, and nine center gimbaled engines, providing enhanced reliability on vehicle ascent with engine-out capability. On both Terran R stages, the LOx propellant tanks are forward of the methane tanks, separated by a printed common dome. Subcooled cryogenic propellants are used on all parts of the vehicle except for the first stage liquid oxygen system, where subcooling is not necessary to meet performance goals. Both stages use a cryogenic helium pressurization system to enable better press authority when engines are not turned on by reducing ullage collapse. The vehicle also features an in-house developed pneumatic pusher stage separation system.
Terran R features two near body-length aero strakes, four unique slider-mechanism landing legs, and four printed actuating grid fins. These features optimize first stage reusability, enabling rapidly scaled launch cadence for customers together with greater payload to orbit and lower costs versus other reusable architectures. Terran R’s innovative first stage architecture allows for a high angle of attack reentry which reduces propellant required for reentry burns, aerodynamic design for better reentry stability and improved control authority, and a passively actuated landing leg deployment system which is elegantly simple, lightweight, and highly operable for rapid reuse. An 18-foot vehicle diameter also aids vehicle stability with lower requirements on landing legs. Terran R will have an electromechanical actuator (EMA)-based engine thrust vector control (TVC) system, and also use EMAs for grid fin control, in addition to in-house developed avionics and flight software. Additionally, the vehicle features a reentry heat shield on the aft end designed for rapid reusability.
Meeting Terran R Market Demand
Relativity is a customer-centric rocket company that is approaching Terran R design and production directly targeted on meeting current, and future, launch service market demand. Terran R is intended to offer a compelling alternative to current market offerings and to become a top choice for customers seeking reliable and cost-effective medium-to-heavy lift payload launch services. As a testament to its commercial viability, Relativity currently has Launch Service Agreements (LSAs) that amount to more than $1.65 billion across seven customers, indicating clear market leadership and strong belief in Terran R’s ability to solve customer needs.
With satellite technology advancements, demand for bandwidth soaring, and satellite constellations representing the largest part of the growing launch market with a Total Addressable Market of over $30B/year by 2030, Terran R was developed to accommodate the growing demand for large constellation launch services. With a payload fairing that offers the right market fit to meet a variety of needs, Terran R supports use cases from dedicated payload deployments of constellation customers or single geosynchronous satellites to rideshare configurations for multiple customers per launch.
Designed for Reusability from Day One
From day one, Terran R was intentionally designed for reusability. The company intends to design major parts of the vehicle for 20 reuses right away, with strategic development of reusability criteria and rapid learning from flight data to continuously improve through successive vehicle block upgrades. Focusing on our customer’s needs for urgent, disruptive, relevant, and diversified launch supply in the medium-to-heavy payload market, we chose to prioritize optimizing for first stage reuse initially. Each early flight of Terran R will seek to deliver customer payloads to orbit reliably. Then, after vehicle ascent, Max-Q, MECO, stage separation, and second stage ignition - with the customer payload well on its way to orbit - the first stage will begin its entry, landing, and reuse journey.
First Stage Reuse Process
Shortly after stage separation, the first stage of Terran R will perform a slow flip maneuver using its cold gas Reaction Control System (RCS). Grid fins deploy, followed by igniting engines to complete entry burns, slowing velocity and reducing peak loads and heating. Vehicle aerosurfaces and strakes are uniquely designed to enable high angle of attack on entry. This reduces the payload penalty for reuse with less propellent used on entry burns. Additionally, unique aerodynamic features result in a more stable entry profile with controlled flow separation around the vehicle. Terran R is designed for atmospheric entry with grid fin control. The vehicle will then ignite engines for a landing burn and command the leg slider mechanism to open, which will then passively deploy with the aid of aerodynamics. The first stage will then touchdown on a downrange ship in the ocean. Once the first stage has completed its reentry, it will go for inspection, refurbishment, and recertification for its next flight from Cape Canaveral.
