Installation of Large Carbon Composite Rocket-Building Machine Underway
Automated Fiber Placement AFP Machine Custom-Designed and Built for Rocket Lab
Installation of the largest automated fiber placement (AFP) machine of its kind is underway at the Rocket Lab Neutron rocket production line in Middle River, MD. The AFP machine will enable the company to automate production of the largest carbon composite rocket structures in history.
"It’s an innovative machine producing a next-generation rocket from one of the birthplaces of the aerospace industry in Baltimore."
Peter Beck, Rocket Lab
The custom-built 99-ton, 39 ft tall robotic machine, American-made by Electroimpact in Washington, has just completed final acceptance testing with the manufacturer and installation has begun at Rocket Lab’s Space Structures Complex in Middle River, Maryland. The new machine will automate the production of all large composite structures of the Neutron launch vehicle including the panels that make up the 91 ft length interstage and fairing, 22.9 ft diameter first stage, and the 16.4 ft diameter second stage tank.
The autonomous machine can move up to 98 ft in length and lay down continuous carbon fiber composite at a rate of 328 ft per minute. The AFP machine also has a fully automated real-time inspection system that hunts for miniscule defects throughout the laminated carbon composite and alerts the machine operator of any issues before the machine begins laying down the next layer, providing additional assurance that these critical structures of the launch vehicle meet Rocket Lab’s high-quality standards required for reusable Neutron launches.
As Neutron’s carbon composite structures move into full-scale production, this autonomous machine is expected to introduce significant time-savings of 150,000+ manufacturing hours into the production process.
"As we build the world’s largest carbon composite rocket, it makes sense that we require a world-first carbon composite fiber placement machine. We’re combining our proprietary flight-proven carbon composite technology, additive manufacturing, and autonomous robotics to design and build large-scale aerospace components at a pace that will support not only Neutron’s launch cadence, but support Electron and carbon composites structures for our spacecraft customers too," said Sir Peter Beck, Rocket Lab founder and CEO. "We worked closely with our excellent partners at Electroimpact to create this robot and we’re thrilled with the results. It’s an innovative machine producing a next-generation rocket from one of the birthplaces of the aerospace industry in Baltimore, and we can’t wait to see its first carbon composite printed panels come off the production line soon.”
The AFP machine will also be leveraged to print smaller carbon composite Neutron structures, first stages of Rocket Lab’s Electron launch vehicle, and other flight-proven carbon composite structures for space including spacecraft structural panels and assemblies, solar panel substrates, carbon composite tanks and primary structures, and custom projects for the aerospace industry.
