Fully Assembled Ariane 6 Rocket Rolled Out to its Launch Pad
The Ariane 6 launch pad at Europe’s Spaceport in French Guiana now hosts for the first time a fully assembled example of ESA’s new heavy-lift rocket, following the addition of an upper composite to the core stage and four boosters already in place. The upper composite – consisting of two half-fairings and a payload mock-up with the structural adapter needed to join it to the core stage – made the six mile trip from the encapsulation building to the launch pad on October 12.
“Innovation is the key to maintaining Europe’s capacity to reach space with a fully independent launch system that is competitive and versatile.”
ESA Director of Space Transportation Daniel Neuenschwander.
Assembly, transfer and installation of an upper composite validates the Ariane 6 assembly process. Now, over the next several weeks, teams from ESA, ArianeGroup and French space agency CNES will make the mechanical, electrical and fluid connections which join this test model of the Ariane 6 configuration to the launch pad.
When fully integrated with the pad, so-called combined tests will validate the rocket, launch pad and shared electrical, fluid and mechanical systems as a complete system. The combined tests include tank filling and drainage operations which guarantee smooth-running of a launch sequence. Flight and control bench software will also be tested.
Ariane 6 Launch Pad Will Serve as Hot Fire Test Stand
Then, the launch pad will serve as a test bed for static hot fire tests of the Vulcain 2.1 core stage engine, including aborted firings and long firings with disconnection. Vulcain 2.1 is derived from Ariane 5’s Vulcain 2.
Separately, static hot-fire tests of the Ariane 6 upper stage and its all-new Vinci engine began in October on a purpose-built test bed at Germany’s DLR center for engine and stage testing at Lampoldshausen. The reignitable Vinci engine allows Ariane 6 to deliver multiple payloads to different orbits on a single launch. After payload separation a final engine burn deorbits the upper stage so that it does not become a debris threat in space.
ESA Director of Space Transportation Daniel Neuenschwander stressed the importance of Ariane 6 as a successor to Ariane 5, which for more than a quarter century has provided Europe with reliable access to space: “Innovation is the key to maintaining Europe’s capacity to reach space with a fully independent launch system that is competitive and versatile,” he said.
“With Ariane 6 we have Europe’s best engineers developing new technologies and manufacturing methods to build on the success of one of the world’s most reliable launch systems.”
(Images provided with ESA news release)
