Fuel Filter a Possible Cause of Launcher One Failure
Virgin Orbit has identified a fuel filter as a possible cause of the failure of its first mission to launch from the UK.
"In space launch, a failure is painful for all involved. Intense disappointment gets quickly channeled into the motivation to dig into the cause, to understand all contributing elements and to thereby get back to flight with a better system and a wiser team."
Virgin Orbit CEO Dan Hart.
Virgin Orbit began its investigation into the failure within hours of the conclusion of the January 9th mission, under the leadership of distinguished aerospace veteran Jim Sponnick and Virgin Orbit Chief Engineer Chad Foerster. The failure investigation team received immediate access to extensive telemetry data collected during the mission from the ground stations in the UK, Ireland, and Spain, as well as systems onboard its carrier aircraft, providing a robust dataset that the investigation team has thoroughly examined.
The investigation has confirmed that the Virgin Orbit team successfully executed pre-flight preparations, carrier aircraft takeoff, captive carry flight, and rocket release. The ignition, first stage flight, stage separation, second stage ignition, and fairing deployment of the LauncherOne rocket were nominal. Each of these milestones constituted a first-of-its-kind achievement for any orbital launch attempt from western Europe. LauncherOne performed successfully on all four prior operational flights, accurately delivering 33 payloads to their required orbits.
Fuel Filter Issue Potentially Degraded Rocket Motor Efficiency
The investigation team is utilizing a comprehensive fault tree, a very detailed timeline, and several other products to conduct the investigation in a rigorous manner. Key observations at this point in the investigation:
The data is indicating that from the beginning of the second stage first burn, a fuel filter within the fuel feedline had been dislodged from its normal position.
Additional data shows that the fuel pump that is downstream of the filter operated at a degraded efficiency level, resulting in the Newton 4 engine being starved for fuel. Performing in this anomalous manner resulted in the engine operating at a significantly higher than rated engine temperature.
Components downstream and in the vicinity of the abnormally hot engine eventually malfunctioned, causing the second stage thrust to terminate prematurely.
The early thrust termination ended the mission, and the second stage and its payloads fell back to Earth, landing in the approved safety corridor in the Atlantic Ocean.
The investigation includes oversight by U.S. Federal Aviation Administration and the UK Air Accidents Investigation Branch (acting as the Space Accident Investigation Authority (SAIA) for the United Kingdom) and also participation by personnel from the Department of Defense, National Transportation Safety Board, and the National Reconnaissance Office. The U.K. Civil Aviation Authority will also be involved in the investigation process.
The investigation is employing a detailed action plan to develop key analyses and tests to replicate flight conditions and to aid in determining the root cause or causes of the failure. All potentially credible scenarios, including the one described above involving the fuel filter, are being investigated. Numerous tests are underway to support the investigation and help lead to definitive conclusions. Ultimately, all credible causes of the failure will be addressed prior to the next LauncherOne mission.
"In space launch, a failure is painful for all involved. Intense disappointment gets quickly channeled into the motivation to dig into the cause, to understand all contributing elements and to thereby get back to flight with a better system and a wiser team," said Virgin Orbit CEO Dan Hart. "Our investigation is not yet complete; the team is hard at work and we’ll pursue the cause and contributors wherever the system analysis takes us. However, with many clear clues from extensive data assessment now understood, we are modifying our next rocket with a more robust filter and we are looking broadly to assure that all credible contributors to mission failure are rooted out and addressed. With those modifications being incorporated on our factory floor, we will proceed cautiously toward the launch of our next rocket, which is well into the integration and test process.”
Virgin Orbit’s next launch will occur from the Mojave Air and Space Port in California for a commercial customer. The company anticipates announcing more details about that mission in the coming weeks.
(Source: Virgin Orbit news release. Images from file)
