European Service Modules in Production at Airbus

Three European Service Modules (ESMs) are being integrated in parallel in Airbus’ Bremen cleanrooms. Integration of ESM-3 is almost complete and ESM-4 is well under way, and the newly arrived ESM-5 structure is now the focus of initial integration steps.

“Together with the European Space Agency, Airbus is providing half the spacecraft that will return humans to the Moon."

Marc Steckling, Head of Space Exploration at Airbus.

Each of the European Service Modules requires the integration of more than 22,000 elements. This is the first time ever that NASA has entrusted a non-US prime, in this case Airbus through ESA, to build a mission-critical element for an American human spaceflight mission.

“Together with the European Space Agency, Airbus is providing half the spacecraft that will return humans to the Moon - taking them further than ever before into space and of course returning them safely to Earth,” said Marc Steckling, Head of Space Exploration at Airbus. “We have already delivered the first two ESMs, with ESM-2 currently being integrated in Orion at Kennedy Space Center. With the arrival of the ESM-4 structure last summer and that of ESM-5 just before Christmas, we have now started the serial production phase. Our cleanroom facilities have been optimized to accommodate three ESMs at the same time, and we are on track to meet NASA’s requirement to deliver one ESM per year going forward.”

European Service Modules are Critical to Artemis

European Service Modules are a critical element of NASA's crewed Orion spaceship as it provides the spacecraft’s main propulsion system while also enabling orbital maneuvering and positioning control. Electrical power generation and distribution are also provided by the ESM along with supplying the crew with the central elements of life support such as water and oxygen. The ESM also regulates thermal control while it is connected to the crew module. In addition, the unpressurised service module can be used to carry additional payloads. ESA has invested about $2.15 billion in the Orion program and contracted Airbus to lead the European consortium and build six ESMs to date.

ESM-2 was delivered to Florida in October 2021. It is now being tested and integrated at the Kennedy Space Center. It will be part of the crewed Artemis II Mission, which will fly the first astronauts around the Moon and back to Earth since 1972. The Artemis II launch is currently planned for 2024.

ESM-3, undergoing final integration, will power the Artemis III Mission, set to see the first woman and first person of color setting foot on the Moon. The delivery of ESM-3 is planned for the second half of 2023. This mission is envisaged for no earlier than 2025.

The ESM-4 structure arrived at Airbus’ Bremen cleanroom in June 2022 and is currently being integrated. The recently arrived ESM-5 structure is already being worked on.

ESMs 4, 5 and 6 will be used for the Artemis IV to VI missions, the first two of which are part of the European contribution to the international Gateway, a space station planned to be assembled in lunar orbit. ESA and NASA are aiming to establish a Moon ecosystem (Gateway, Argonaut) to better understand and explore all the Moon has to offer and in the longer-term to prepare for crewed missions to Mars.

Further European Service Modules … 7, 8 and 9 … were authorized at the ESA ministerial council in November 2022, and Airbus is currently finalizing its offer to provide them.

The Orion ESM is cylindrical in shape and approximately 13 feet in diameter and height. At launch, it weighs just over 13 metric tons, making up roughly 60% of the Orion spacecraft’s total mass. Its 8.6 metric tons of fuel power the main engine, eight auxiliary thrusters and 24 smaller thrusters used for attitude control. The European Service Module is installed underneath the crew module at Kennedy Space Center in Florida. Together, they form the Orion spacecraft.

Airbus engineers produce the European Service Modules together with ESA and industry partners, including suppliers from 10 countries. ESM manufacturing builds on Airbus’ experience gained on the Automated Transfer Vehicle (ATV), which flew five times to the ISS between 2008 and 2015.

(Source: Airbus. Images provided)
